HE359DAC007/107 Analog Output Module
Brand: Horner
SmartMod I/O is a RTU/Modbus based I/O system designed to fill-out the I/O complement for applications utilizing XLe, LX, or any other OCS/RCS family Controller.
As many as 31 SmartMod I/O modules may be daisy chained on a single RS-485 link.
SmartMod I/O is DIN-rail mounted, powered from 10-30 Vdc, and features 2,000 Vac optical isolation.
007: 2-channel Analog Outputs, selectable between Voltage (0-10 Vdc) and Current (0-20 mA), 1 mV or 1 μA resolution, 2,000 Vac isolation (ch-RS485 & ch-power) .
107: 4-channel Analog Outputs, selectable between Voltage (0-10 Vdc) and Current (0-20 mA), 1 mV or 1 μA resolution, 2,000 Vac isolation (ch-RS485 & ch-power).
Displaying prices & availability for Ohio, United States in CAD. Change location.
Models matching criteria: 2
25+ In Stock
$330.00 CAD
Does not ship to OH, United States
14 In Stock
$405.00 CAD
Does not ship to OH, United States
Specifications
Brand
Approvals & Certifications
- CE
- UL
Channels
- 2
- 4
Communication
- Modbus/RTU (Binary)
- RS-485
Humidity
- 0 to 90 % Non-Condensing
Isolation
- 2,000 Vac for 60 seconds (Input/Power & Input/Comms)
Load
- Resistance Current: 5 kiloohms
Operating Temperature
- -10° to 60° C (14° to 140° F)
Output
- 0-10 V
- Output Calibration Current: ± 20 μA
- Output Calibration Voltage: ± 10 mV
- Range: 0-20 mA
Power Requirement
- Steady State: 30 mA at 24 Vdc, Typical (100 mA - Max.
Power Supply
- External Voltage: 18-30 Vdc
Resolution
- 1 µA
- 1 mV
Storage Temperature
- -40° to 85° C (-40° to 185° F)
