EST110 multi-point temperature sensor wire can measure temperature of grain in different positions of the silo in real time, to record condition of the grain and provide you the optimal monitoring of grain storage quality.
Relative to the traditional silo, manual temperature measurement is time-consuming and arduous.
The temperature measured by EST110 is digital signal, which can output RS485 communication mode through matching with HubLink 1-wire to transmit information to the central control room or human-machine interface.
The user can easily know the grain temperature in the silo only from the remote end and conduct the most efficient grain storage management.
Features- Reinforced steel cable design can effectively resist the impact of grain and prolong service life of the product
- Provide multi-point temperature measurement to help managers cope with food more swiftly
- Detect whether there is fungus produced or activities of insects, to maintain food quality
- Provide real-time monitoring of silo temperature for practitioners in food, fodder and grain, to help long-term storage
- Prevent qualitative change of grain in the silo and fire disaster due to smolder
- Temperature measurement position can be customized according to customer’s requirements, which can be hung outside or built in the silo
Specifications
Brand
Accuracy
- ± 0.5° C (± 0.9° F)
Approvals & Certifications
- CE
Cable Material
- Coated with PVC, Inner Ring is Copper Wire
Diameter
- Outgoing Cable Diameter: Ø 4 to 8 mm
Enclosure, Body Material
- Low-Carbon Steel (Stainless Steel 41)
Environmental Protection
- IP67
Flange Size - 1-1/2” (DN 40)
- 1-1/2” (DN 40) - 150#
- 1-1/2” (DN 40) - 300#
- 1-1/2” (DN 40) - JIS 10K
- 1-1/2” (DN 40) - JIS 5K
Flange Size - 2-1/2” (DN 65)
- 2-1/2” (DN 65) - 150#
- 2-1/2” (DN 65) - 300#
- 2-1/2” (DN 65) - JIS 10K
- 2-1/2” (DN 65) - JIS 5K
Flange Size - 2” (DN 50)
- 2” (DN 50) - 150#
- 2” (DN 50) - 300#
- 2” (DN 50) - JIS 10K
- 2” (DN 50) - JIS 5K
Flange Size - 3” (DN 80)
- 3” (DN 80) - 150#
- 3” (DN 80) - 300#
- 3” (DN 80) - JIS 10K
- 3” (DN 80) - JIS 5K
Flange Size - 4” (DN 100)
- 4” (DN 100) - 150#
- 4” (DN 100) - 300#
- 4” (DN 100) - JIS 10K
- 4” (DN 100) - JIS 5K
Flange Size - 5” (DN 125)
- 5” (DN 125) - 150#
- 5” (DN 125) - 300#
- 5” (DN 125) - JIS 10K
- 5” (DN 125) - JIS 5K
Flange Size - 6” (DN 150)
- 6” (DN 150) - 150#
- 6” (DN 150) - 300#
- 6” (DN 150) - JIS 10K
- 6” (DN 150) - JIS 5K
Length
- 100 feet (30 metres) - Max.
Load
- Tensile Load (PE): 4,000 kgf
- Tensile Load (PVC): 3,000 kgf
Media
- Solids
Resolution
- 0.1° C (0.18° F)
Temperature Range
- -10° to 85° C (14° to 185° F)
