WU20 Electrode Cable

Brand: Yokogawa Electric Corporation

The program of Yokogawa includes a range of high quality, low-noise cables for accurate transmission of low voltage signals even in areas where interference is present.

They have a shield with an internal anti-noise sheath and can be connected to all pH and ORP (Redox) electrodes fitted with an O-connector.

At the electrode end the cables are provided with a socket having spring gilded contacts for secure connection to the sensor.

The combination electrode plug and cable socket is watertight and temperature resistant up to 125° C. It meets the requirements of IP65.
Features
  • Internal anti-noise sheath for accurate measurement
  • Gold plated spring O-connectors parts, for good electrical contact under the most severe conditions
  • Coaxial plug and socket with watertight sealing that meets the requirements of IP65
  • Cables for industrial applications and for laboratory use are available

Specifications

Applications

  • Industrial Applications
  • Laboratories

Cable Length

  • 3.2 to 82 feet (1 to 25 metres)

Electrical Connectors

  • 2 mm Contact Pins - Wire Connections

Electrical Contacts

  • Gold-Plated Spring O-Connectors Parts - Good Electrical Contact

Environmental Protection

  • Intrinsically Safe
  • IP65
  • Watertight

Length

  • 50 mm - Bending Radius

Temperature Range

  • Maximum

  • Industrial Applications
  • Laboratories
